19 EMS COMPONENTS 75
L00567-10
Select Start Calibration Read. The current sensor value is displayed in [bit] in the REAL_TIME_GEAR field.
L00568-10
Release screws
1
and change the position of the gear position sensor
2
until
the specified value is reached.
Guideline
REAL_TIME_GEAR 51 bit
Tighten the screws.
Guideline
Screw, gear position sen-
sor
M5 6 Nm
(4.4 lbf ft)
Loctite
®
243™
