5. - Machine specifications
FC313RF
31
KN021BGB K
Mower conditioner
For machines with serial number as from
B0266.
0
1 : Main frame 2 : Mowing unit
3 : Parking stand 4 : Lateral parking stand
5 : Hydro-pneumatic accumulator 6 : Swath shield
7 : Transport lock lever 8 : Cutterbar
9 : Central gearbox 10 : Side gearbox
11 : Lift cylinder 12 : Pressure gauge
13 : Conditioning roller 14 : Transport lock
15 : Side guard
8
15
13
5
14
12
10
1
2
3
3
11
11
15
4
6
7
9
5
1
3
3
11
11
12
15
