10. - Maintenance and storage
FC313RF
67
KN021BGB K
Mower conditioner
10.3.1 PTO shaft
Primary PTO shaft
Place the machine in working position.
Stop the tractor engine and remove ignition
key.
Before using the machine for the first time:
- Grease the transmission.
During intensive use with tractors of
maximum authorized power, it is
recommended to grease at closer intervals.
- Every 50 hours:
• transmission tube (2).
- Every 100 hours:
• U-joints (1).
• Guide rings (3).
