KUHN FC313RF - Chain Replacement and Roller Synchronization

FC313RF
80
10. - Maintenance and storage
KN021BGB K
Mower conditioner
10.4.5 Chain replacement and roller
synchronization
To replace the chain:
- Remove 3 bolts (1).
- Remove chain guard (2).
- Unscrew 2 bolts (1).
- Pivot tensioning device to slacken chain
slightly (a).
- Remove quick release link (3) and then chain (2).
1
2
2
1
3
a
b
