10. - Maintenance and storage
FC313RF
89
KN021BGB K
Mower conditioner
10.4.11Disc replacement
Inner disc
Intermediate discs
The replacement of the inner disk must be
carried out by your Kuhn authorized dealer.
- Place a wooden wedge (2) between two discs to
stop them from moving.
- Remove 2 bolts (1) and their spring washers using
the box spanner supplied with the machine.
- Remove the disc conical cover.
- Remove the 2 other nipple-screws and their spring
washers.
- Remove the disc.
