FC313RF
90
10. - Maintenance and storage
KN021BGB K
Mower conditioner
When remounting:
- Position their largest diameters at right angles to
each other.
- Position conical centre of spring washer at the
top.
- Tighten screws:
• Torque: 12 daN m (89 lbf ft).
Check if there is still a gap of 1 mm (0.04’’)
between the disc lower part and the cutterbar
wear plates.
If this is not the case, fit one (maximum two)
spacer(s) between the disc and the mounting
hub (Part no. 56807100).
