7. - Instructions for transport
KN021BGB K
Mower conditioner
7. Instructions for transport
7.1 Putting the machine into
transport position
The machine is in transport position.
Before placing the machine into transport
position:
Wait until the rotating parts have come to a
complete stop.
From the working position:
- Release and fold side guards upwards using 18
box spanner supplied with the machine.
- Lift transport lock lever in transport position.
- Lift mowing unit using machine lift cylinders to
engage transport locks.
- The machine automatically locks in transport
position.
Check that transport locks are engaged.
If the machine transport locks do not engage
automatically:
• The spacer is distorted (1).
• Replace spacer.
1
Never engage the tractor PTO drive when the
machine is in transport position.
