FC313RF
34
6. - Putting into service
KN021BGB K
Mower conditioner
6.2.2 Preparing the tractor
The tractor PTO stub must rotate at a speed of
1000 min
-1
.
The tractor must be fitted with the following
components:
• 1 single acting valve with float position.
• 1 standard ISO 5676 female plug.
For tractors fitted with a front lift linkage with
double acting cylinders, these must be set in
detented float position to allow the lift linkage
to travel up and down at will.
Modification work to the tractor's hydraulics
must be undertaken by an authorized
specialist.
