KUHN FC313RF - Machine Specifications; Description and Glossary

FC313RF
30
5. - Machine specifications
KN021BGB K
Mower conditioner
5. Machine specifications
5.1 Description and glossary
For machines up to serial number B0265.
0
1 : Main frame 2 : Mowing unit
3 : Parking stand 4 : Lateral parking stand
5 : Hydro-pneumatic accumulators 6 : Swath shield
7 : Transport lock lever 8 : Cutterbar
9 : Central gearbox 10 : Side gearbox
11 : Lift cylinder 12 : Pressure gauge
13 : Conditioning roller 14 : Transport lock
15 : Side guard
8
15
13
5
14
12
10
1
2
3
3
11
11
15
4
6
7
9
