FC313RF
84
10. - Maintenance and storage
KN021BGB K
Mower conditioner
10.4.7 Replacing the belts
Never replace belts individually. When a belt is
damaged, always replace the whole set.
- Remove 3 bolts (1).
- Remove belt guard (2).
- Loosen counter nut (3).
- Loosen nut (4).
- Replace belts in full sets.
- Reinstall belt guard:
• Torque: 8.5 daN m (63 lbf ft).
- Adjust belt tension.
