6. - Putting into service
FC313RF
35
KN021BGB K
Mower conditioner
Additional valve
Adjustment:
- Couple the machine to the tractor.
- Rotate the 3 way valve so that oil will be directed
to the tractor front linkage cylinders rather than to
the machine lift cylinders.
- Adjust the tractor's front lift linkage height.
- Rotate the 3 way valve so that oil is directed to the
machine lift cylinders rather than to the tractor front
linkage cylinders.
If the tractor has no additional single acting valve
with float position:
- Install a 3 way valve similar to the one used to
adjust the pressure in the hydro-pneumatic
accumulators.
This operation must be carried out by an
authorized specialist.
See section: Putting into service / Coupling and
uncoupling / Adjusting the machine / Frame
height and check chains.
After adjustment, the mowing unit lift cylinders
are controlled by the directional control valves of
the tractor's cylinders.
