FC313RF
36
6. - Putting into service
KN021BGB K
Mower conditioner
Quick release "A" frame coupler
- Adjust the top link length so that the "A" frame
coupler is approximately vertical with regards to
the ground.
- Attach the quick release "A" frame coupler to the
tractor's front lift linkage using the hitch pins
supplied with the machine.
- Attach check chains on hitch pins and secure using
washers, roll pins and lynch pins.
