FC313RF
74
10. - Maintenance and storage
KN021BGB K
Mower conditioner
Central gearbox
Before draining oil, operate the machine for a few
minutes so that the oil warms up.
The angle gearbox is lubricated with 2.5 L (0.66 US gal) of extreme-pressure oil for mechanical
transmissions with viscosity grade SAE 80W90 and API grade GL5.
When draining and refilling, it is recommended to use either a mineral base oil with viscosity grade
SAE 80W90 and API grade GL5, or a synthetic base oil, type PAO (Poly-Alpha-Olefins) with a viscosity
grade equivalent to SAE 80W90.
- Remove the filler plug (1).
- Place a container of sufficient capacity under drain
plug.
- Remove drain plug (2).
- Allow oil to drain completely.
- Wait for dripping to stop.
- Clean and reinstall drain plug (2).
- Pour the correct oil quantity and quality through the
opening of the filler plug (1).
- Check central gearbox oil level.
