FC3160-3560-4060 TCD
58
8. - Instructions for work
KN284EGB_A
Mower conditioner
- Turn counter-clockwise to decrease the ground
pressure.
- Turn clockwise to increase the ground pressure.
- Position the mowing unit in headland turn
position for easier wrench rotation.
30 (1) mm wrench.
Should you have difficulties in adjusting the
mowing unit ground pressure, it may be
necessary to adjust the ground pressure
system's torsion bars. (See maintenance and
storage chapter).
8.2.3 Finger conditioning rotor speed
Always place the machine in working
position before making rotor speed
(rotational frequency) adjustments.
The machine is equipped with a finger conditioning
rotor. The rotor speed can be adjusted to 780 min-1
or 1000 min-1. At delivery, the speed is set at
1000 rpm.

Rotor speed adjustment
- Turn off the engine, remove ignition key
and wait until all moving parts have come
to a complete stop.
a
b
1
