KUHN FC3160 TCD - Adjusting the Machine

FC3160-3560-4060 TCD
48
6. - Putting into service
KN284EGB_A
Mower conditioner
6.2.10 Adjusting the machine
Lateral adjustment of the lower links.
- Balance the play on either sides of the lift linkage
and lock lower link stabilizers.
Frame height and check chains
- Lower tractor lift linkage to obtain a distance (H)
slightly exceeding 650 mm (2’1.6’’) between the
hitch pins and the ground.
=
=
L
H
