Interbus 1.1
1.4 Trademarks
Windows is a trademark of Microsoft Corporation.
1.5 Terms used
Tip to make your work easier or reference to further information.
Term Description
CMD Configuration, Monitoring, Diagnostic: software
for configuration, monitoring and troubleshooting
in Interbus interfaces.
CR Communication reference.
DTM Device Type Manager
Device description file
I/O Inputs/outputs, e.g. at terminals and on
machines.
Remote bus Designation for the main ring of an Interbus sys-
tem
FSMA Field-installable SubMiniature Assembly: Fiber-
optic connector with screw lock, outwardly simi-
lar to the electrical SMA connector.
FW Firmware: normally unchangeable operating
software of a device which is automatically
loaded when the device is activated.
HCS fiber HCS fiber (Hard Cladded Silica): a FOC variant
consisting of a glass fiber core with a plastic
cladding.
HW Hardware: physical, electronic components and
modules.
IBS Interbus
Interbus A field bus introduced by Phoenix Contact. It is
defined as a ring system in which every device
regenerates and forwards the incoming signal.
The Interbus offers high data throughput at a low
cycle rate and is particularly immune to interfer-
ence. It is defined for normal copper cables and
also for fiber-optic cables. Up to 512 slaves can
be connected to an Interbus (master-slave struc-
ture) and up to 4096 I/Os can be served. The
main ring (remote bus) can contain up to 256
devices; local buses or loop segments can be
coupled, e.g. in a machine, by means of bus
couplers.
ISA Industry Standard Architecture: commonly-used
PC bus before PCI.
