KWB Easyfire - Cleaning the Fill Level Sensor in the Suction Tank; Interruption of Operation

Cleaning the fill level sensor in the suction tank
m
Dust deposits can interfere with the sensor measurements!
4
Remove the suction tank cover.
4
Unscrew the three screw connections to the turbine plate in order to be able to lever out
the entire turbine.
4
Carefully clean the facing surface of the fill level sensor using a brush.
4
Reinsert the turbine plate – when securing, use the spacer rubbers (6), rubber discs (4)
and metal washers as shown on the side.
4
Place on the cover again – make sure it seals tightly!
Interruption of operation
You should perform the following steps if you do NOT use the heating system for several
weeks (e.g. summer break):
4
Clean the combustion chamber (vacuum).
4
Close all doors.
If you do NOT use the heating system in the winter, then have the system emptied completely
to protect against frost.
Attention! Protect the environment: If your heating water contains antifreeze, please comply
with the regulations for the disposal of antifreeze!
7.4.7
1
2
6
3
4
5
7.5
7
Maintenance
Interruption of operation
50
B KWB Easyfire EN, 05.2011
