Kyocera FS-C5350DN Service Manual

2K8
2-3-3
Connector Pin Signal I/O Voltage Description
YC3 1 FEMOTRDYN I 0/3.3 V DC Paper feed motor ready signal
Connected
to the paper
feed motor,
intermedi-
ate clutch
and duplex
clutch
2 SPEEDSEL O 0/3.3 V DC Paper feed motor speed switch signal
3 FEMOTCLK O 0/3.3 V DC (pulse) Paper feed motor clock signal
4 FEMOTREN O 0/3.3 V DC Paper feed motor: On/Off
5 GND - - Ground
6 +24V3 O 24 V DC 24 V DC power source
7 MIDCLDRN O 0/24 V DC Intermediate clutch: On/Off
8 +24V3 O 24 V DC 24 V DC power source
9 DUCLDRN O 0/24 V DC Duplex clutch: On/Off
10 +24V3 O 24 V DC 24 V DC power source
YC5 1 +5V1 O 5 V DC 5 V DC power source
Connected
to the left ID
sensor
2 LEDREFL O Analog Left ID sensor control signal
3 GND - - Ground
4 VOPL I Analog Left ID sensor detection signal
5 VOSL I Analog Left ID sensor detection signal
YC6 1 +5V1 O 5 V DC 5 V DC power source
Connected
to the right
ID sensor
2 LEDREFR O Analog Right ID sensor control signal
3 GND I - Ground
4 VOPR I Analog Right ID sensor detection signal
5 VOSR I Analog Right ID sensor detection signal
YC7 1 GND - - Ground
Connected
to the regis-
tration sen-
sor
2 REGPAP I 0/5 V DC Registration sensor: On/Off
3 +5V2 O 5 V DC 5 V DC power source
YC9 1 CAS2 I 0/3.3 V DC Cassette size switch (SW2): On/Off
Connected
to the cas-
sette size
switch
2 CAS1 I 0/3.3 V DC Cassette size switch (SW1): On/Off
3 COM - - Ground
4 CAS0 I 0/3.3 V DC Cassette size switch (SW0): On/Off
YC10 1 +24V1 O 24 V DC 24 V DC power source
Connected
to the devel-
oping fan
motor 1
2 DLPFANDRN O 0/12/24 V DC Developing fan motor 1: Full speed/Half speed/Off
YC11 1 +24V1 O 24 V DC 24 V DC power source
Connected
to the ozone
fan motor
2 OZFANDRN O 0/12/24 V DC Ozone fan motor: Full speed/Half speed/Off
YC12 1 LEDA O 5 V DC 5 V DC power source
Connected
to the waste
toner full
sensor
2 LEDK O 0/5 V DC (pulse) Waste toner full sensor (emitter)
3 PTRE I Analog Waste toner full sensor (receiver)
4 PTRC O 5 V DC 5 V DC power source

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
