Kyocera FS-C5350DN Service Manual

2K8
2-3-4
YC13 1 +24V1 O 24 V DC 24 V DC power source
Connected
to the inter-
lock switch
2 N.C. - - Not used
3 +24V2 I 24/0 V DC
24 V DC power source
Interlock switch: On/Off
YC14 1 +24V3 O 24 V DC 24 V DC power source
Connected
to the left
cover switch
2 N.C. - - Not used
3 +24V4 I 24/0 V DC 24 V DC power source
Left cover switch: On/Off
YC16 1 GND - - Ground
Connected
to the high
voltage
PWB
2 GND - - Ground
3 HVCLKK O 0/3.3 V DC (pulse) Developing bias clock signal (Black)
4 HVCLKY O 0/3.3 V DC (pulse) Developing bias clock signal (Yellow)
5 HVCLKC O 0/3.3 V DC (pulse) Developing bias clock signal (Cyan)
6 HVCLKM O 0/3.3 V DC (pulse) Developing bias clock signal (Magenta)
7 T2RREMN O 0/3.3 V DC (pulse) Secondary transfer bias reverse signal
8 MKCNT O PWM Main charger high voltage control voltage (Black)
9 BKSCNT O PWM Developing sleeve bias control voltage (Black)
10 BKMCNT O PWM Developing magnet bias control voltage (Black)
11 MYCNT O PWM Main charger high voltage control voltage (Yellow)
12 BYSCNT O PWM Developing sleeve bias control voltage (Yellow)
13 BYMCNT O PWM Developing magnet bias control voltage (Yellow)
14 MCCNT O PWM Main charger high voltage control voltage (Cyan)
15 BCSCNT O PWM Developing sleeve bias control voltage (Cyan)
16 BCMCNT O PWM Developing magnet bias control voltage (Cyan)
17 MMCNT O PWM Main charger high voltage control voltage (Magenta)
18 BMSCNT O PWM Developing sleeve bias control voltage (Magenta)
19 BMMCNT O PWM Developing magnet bias control voltage (Magenta)
20 CLCNT O PWM Cleaning bias control voltage
21 T1MCNT O PWM Primary transfer bias control voltage (Magenta)
22 T1CCNT O PWM Primary transfer bias control voltage (Cyan)
23 T1YCNT O PWM Primary transfer bias control voltage (Yellow)
24 T1KCNT O PWM Primary transfer bias control voltage (Black)
25 T2CNT O PWM Secondary transfer bias control voltage
26 +24V4 O 24 V DC 24 V DC power source
27 +24V4 O 24 V DC 24 V DC power source
YC17 1 STDUBN O 0/24 V DC (pulse) Duplex motor drive control signal (_B)
Connected
to the
duplex
motor
2 STDUAN O 0/24 V DC (pulse) Duplex motor drive control signal (_A)
3 STDUB O 0/24 V DC (pulse) Duplex motor drive control signal (B)
4 STDUA O 0/24 V DC (pulse) Duplex motor drive control signal (A)
Connector Pin Signal I/O Voltage Description

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
