Kyocera FS-C5350DN Service Manual

2K8
2-3-8
YC31 A1 VDOMP I LVDS
APC PWB M video data signal (+)
Connected
to the main
PWB
A2 VDOMN I LVDS APC PWB M video data signal (-)
A3 VDOYP I LVDS APC PWB Y video data signal (+)
A4 VDOYN I LVDS APC PWB Y video data signal (-)
A5 GND - - Ground
A6 PDMN O
0/3.3 V DC (pulse)
Horizontal synchronization signal
A7 PDYN O
0/3.3 V DC (pulse)
Horizontal synchronization signal
A8 GND - - Ground
A9 FPDATA I/O 0/3.3 V DC Operation panel PWB data signal
A10 FPDIR I 0/3.3 V DC Operation panel PWB communication direct signal
A11 +3.3V1 O 3.3 V DC 3.3 V DC power source
A12 +3.3V1 O 3.3 V DC 3.3 V DC power source
A13 SO O
0/3.3 V DC (pulse)
Main PWB serial communication data signal
A14 SDIR O 0/3.3 V DC Main PWB communication direction signal
A15 EGIRN O 0/3.3 V DC Engine interrupt signal
A16 +5V1 O 5 V DC 5 V DC power source
A17 +5V1 O 5 V DC 5 V DC power source
A18 +5V1 O 5 V DC 5 V DC power source
A19 RESETN O 0/3.3 V DC Main PWB reset signal
A20 GND - - Ground
B1 VDOCP I LVDS APC PWB C video data signal (+)
B2 VDOCN I LVDS APC PWB C video data signal (-)
B3 VDOCP I LVDS APC PWB K video data signal (+)
B4 VDOCN I LVDS APC PWB K video data signal (-)
B5 GND - - Ground
B6 PDCN O
0/3.3 V DC (pulse)
Horizontal synchronization signal
B7 PDKN O
0/3.3 V DC (pulse)
Horizontal synchronization signal
B8 GND - - Ground
B9 N.C. - - Not used
B10 FPCLK I 0/3.3 V DC Operation panel PWB clock signal
B11 FPRSTN I 0/3.3 V DC Operation panel reset signal
B12 +3.3V1 O 3.3 V DC 3.3 V DC power source
B13 SI O
0/3.3 V DC (pulse)
Main PWB serial communication data signal
B14 SCLN O
0/3.3 V DC (pulse)
Main PWB clock signal
B15 SBSY O 0/3.3 V DC Main PWB busy signal
B16 VSYNC O 0/3.3 V DC PD mask control signal
B17 EEDAT I/O
0/3.3 V DC (pulse)
EEPROM data signal
B18 EECLK O
0/3.3 V DC (pulse)
EEPROM clock signal
B19 GND - - Ground
B20 GND - - Ground
YC32 1 GND - - Ground
Connected
to the opera-
tion panel
PWB
2 FPCLK O 0/3.3 V DC (pulse) Operation panel PWB clock signal
3 FPDIR O 0/3.3 V DC Operation panel PWB communication direct signal
4 FPDATA I/O 0/3.3 V DC Operation panel PWB data signal
5 +3.3V1 O 3.3 V DC 3.3 V DC power source
6 FPRSTN O 0/3.3 V DC Operation panel reset signal
7 +5V O 5 V DC 5 V DC power source
Connector Pin Signal I/O Voltage Description

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
