Kyocera FS-C5350DN Service Manual

2K8
2-3-9
YC33 1 GND - - Ground
Connected
to the option
paper feeder
2 OPSCLK O 0/5 V DC (pulse) Paper feeder clock signal
3 OPRDYN I 0/5 V DC Paper feeder ready signal
4 OPSDI I 0/5 V DC (pulse) Paper feeder serial communication data signal
5 OPSDO O 0/5 V DC (pulse) Paper feeder serial communication data signal
6 OP5V O 5 V DC 5 V DC power source
7 GND - - Ground
8 OPSEL0 O 0/5 V DC Paper feeder selection signal
9 OPSEL1 O 0/5 V DC Paper feeder selection signal
10 OPSEL2 O 0/5 V DC Paper feeder selection signal
11 OP24 O 24 V DC 24 V DC power source
YC34 1 ERASEMDR O 0/24 V DC Eraser lamp M: On/Off
Connected
to the drum
relay signal
2 TNSENM I Analog Toner sensor M detection voltage
3 ERASECDR O 0/24 V DC Eraser lamp C: On/Off
4 TNSENC I Analog Toner sensor C detection voltage
5 ERASEYDR O 0/24 V DC Eraser lamp Y: On/Off
6 TNSENY I Analog Toner sensor Y detection voltage
7EECLK O
0/3.3 V DC (pulse)
EEPROM clock signal
8 GND - - Ground
9EEDATA I/O
0/3.3 V DC (pulse)
EEPROM data signal
10 +3.3V1 O 3.3 V DC 3.3 V DC power source
11 ERASEKDR O 0/24 V DC Eraser lamp K: On/Off
12 +3.3V2 O 3.3 V DC 3.3 V DC power source
13 TNSENK I Analog Toner sensor K detection voltage
14 DLPTHERM I Analog Developing thermistor detection voltage
YC36 1 MCHMOTA O 24/0 V DC Main charger cleaning motor: Fwd/Stop/(Rev)
Connected
to the main
charger
cleaning
motor
2 MCHMOTB O 24/0 V DC Main charger cleaning motor: Rev/Stop/(Fwd)
YC37 1 LSUMOTA O 24/0 V DC LSU cleaning motor: Fwd/Stop/(Rev)
Connected
to the LSU
cleaning
motor
2 LSUMOTB O 24/0 V DC LSU cleaning motor: Rev/Stop/(Fwd)
YC38 1 +24V1 O 24 V DC 24 V DC power source
Connected
to the power
source fan
motor
2 PSFANDRN O 0/12/24 V DC Power source fan motor: Full speed/Half speed/Off
YC39 1 STFUBN O 0/24 V DC (pulse) Fuser motor drive control signal (_B)
Connected
to the fuser
motor
2 STFUAN O 0/24 V DC (pulse) Fuser motor drive control signal (_A)
3 STFUB O 0/24 V DC (pulse) Fuser motor drive control signal (B)
4 STFUA O 0/24 V DC (pulse) Fuser motor drive control signal (A)
YC40 1 +24V3 O 24 V DC 24 V DC power source
Connected
to the MP
paper feed
solenoid
2 MPSOLDRN O 0/24 V DC MP paper feed solenoid: On/Off
Connector Pin Signal I/O Voltage Description

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
