2A3/4
2-1-3
Machine front side Machine inside
1
2
3
4
Machine back side
Figure 2-1-2 Copier (switches and sensors in the scanning system)
1. Scanner home position switch (SHPSW) ....Detects the scanner in the home
position.
2. Original detection switch (ODSW) ...............Operates the original size sensors.
3. Original size sensors 1 (OSD1) ...................Detects the original size.
4.*Original size sensors 2 (OSD2) ...................Detects the original size.
* For inch specifications only.
