Kyocera KM-4230

3-1-14
2A3/4
14. Open the SRDF and remove the paper from the contact glass.
15. Remove the protective film from the edge of the contact glass.
16. Remove the tape holding the original detection switch.
Original detection switch
SRDF
Paper
Protective film
Figure 3-1-13
