(11) The leading edge of the
image is consistently
misaligned with the
original.
Causes
1. Misadjusted leading edge registration.
Causes Check procedures/corrective measures
1. Misadjusted leading edge
registration.
Readjust the leading edge registration (see
pages 3-3-18 and 39).
(12) The leading edge of the
image is sporadically
misaligned with the
original.
Causes
1. Registration clutch, bypass paper feed clutch or
upper or lower paper feed clutch installed or
operating incorrectly.
Causes Check procedures/corrective measures
1. Registration clutch, bypass paper
feed clutch or upper or lower
paper feed clutch installed or
operating incorrectly.
Check the installation position and operation
of the registration clutch, bypass paper feed
clutch and upper and lower paper feed
clutches. If any of them operates incorrectly,
replace it.
