Kyocera KM-4230

2A3/4
3-6-38
Terminals (CN) Voltage Remarks
1-42 2-B10 0/5 V DC DM LOCK signal, output
1-43 2-B10 0/5 V DC PWSW-L (DIG2) on/off, output (inch specs)
1-44 2-B10 0/5 V DC PWSW-L (DIG1) on/off, output (inch specs)
1-45 2-B10 0/5 V DC PWSW-L (DIG0) on/off, output (inch specs)
1-46 2-B10 0/5 V DC PLSW-L on/off, output
1-47 2-B10 0/5 V DC PWSW-U (DIG2) on/off, output (inch
specs)
1-48 2-B10 0/5 V DC PWSW-U (DIG1) on/off, output (inch
specs)
1-49 2-B10 0/5 V DC PWSW-U (DIG0) on/off, output (inch
specs)
1-50 2-B10 0/5 V DC PLSW-U on/off, output
1-51 2-B10 0/5 V DC BYPPWSW (DIG2) on/off, output
1-52 2-B10 0/5 V DC BYPPWSW (DIG1) on/off, output
1-53 2-B10 0/5 V DC BYPPWSW (DIG0) on/off, output
1-54 2-B10 0/5 V DC BYPPLSW on/off, output
1-55 2-B10 0/5 V DC PSW-L on/off, output
1-56 2-B10 0/5 V DC PSW-U on/off, output
1-57 2-B10 0/5 V DC BYPPSW on/off, output
1-58 2-B10 5/0 V DC LICSW-L on/off, output
1-59 2-B10 5/0 V DC LICSW-U on/off, output
1-60 2-B10 0/5 V DC BYPEDSW on/off, output
1-61 2-B10 5/0 V DC SRHPSW on/off, output
1-62 2-B10 0/5 V DC Duplex unit installed/not installed, output
1-63 2-B10 0/5 V DC Key card*
3
ENABLE signal, output
1-64 2-B10 0/5 V DC Key card*
3
, key counter*
1
connected/not
connected, output
1-65 2-B10 0/5 V DC Key card*
3
control signal, input
1-66 2-B10 0/5 V DC Key card*
3
control signal, input
1-67 2-B10 0/5 V DC Key card*
3
control signal, input
1-68 2-B10 0/5 V DC Key card*
3
control signal, input
1-69 2-B10 5 V DC Control voltage for MPCB, output
1-70 2-B10 5/0 V DC Control voltage for MPCB, output
1-71 2-B10 0/24 V DC IFFM on/off, input
1-72 2-B10 0/24 V DC CL on/off, input
1-73 2-B10 0/5 V DC (pulse) TFM/TRM drive clock pulse, input
1-75 2-B10 0/5 V DC TFM drive control signal, input
1-76 2-B10 0/5 V DC TRM drive control signal, input
*1: Optional. *3: Optional for 120 V specifications only.
