2A3/4
3-6-41
Terminals (CN) Voltage Remarks
2-B12 2-B10 24 V DC 24 V DC supply for TNS, output
3-A1 3-A3 0/5 V DC SBESW on/off, input
3-A2 3-A3 5 V DC 5 V DC supply for SBESW, output
3-A4 3-A6 0/5 V DC FSSW on/off, input
3-A5 3-A6 5 V DC 5 V DC supply for FSSW, output
3-A7 3-A6 24 V DC 24 V DC supply for FSSOL, output
3-A8 3-A6 0/24 V DC FSSOL latch-on signal, output
3-A9 3-A6 0/24 V DC FSSOL release signal, output
3-A10 3-A6 0/24 V DC 24 V DC supply for ESCL, output
3-A11 3-A6 0/24 V DC ESCL on/off, output
3-B1 3-A6 24 V DC 24 V DC supply for TC, output
3-B2 3-A6 0/5 V DC TC on/off, input
3-B3 3-A6 24 V DC 24 V DC supply for CFM1, output
3-B4 3-A6 0/5 V DC CFM1 on/off, output
3-B5 3-A6 24 V DC 24 V DC supply for CFM2, output
3-B6 3-A6 0/5 V DC CFM2 on/off, output
3-B7 3-B11 5 V DC 5 V DC supply for FTH, output
3-B8 3-B11 0 - 5 V DC FTH detection voltage, input
3-B9 3-B11 0/5 V DC ESW on/off, input
3-B10 3-B11 5 V DC 5 V DC supply for ESW, output
4-1 3-B11 24/0 V DC SSW1 on/off, input
4-2 3-B11 24/0 V DC SSW2 on/off SOURCE, output
4-3 3-B11 24/0 V DC SSW3 on/off, input
4-4 3-B11 24/0 V DC PRY on/off SOURCE, output
4-5 3-B11 24/0 V DC 24 V DC supply for MSW, output
4-6 3-B11 0/24 V DC Control voltage for SSW1, output
4-7 3-B11 24/0 V DC SSW2 on/off, input
4-8 3-B11 24/0 V DC SSW3 on/off SOURCE, output
4-9 3-B11 24/0 V DC PRY on/off, output
4-10 3-B11 24/0 V DC MSW off signal, output
5-A1 5-A2 ETTH detection voltage, input
5-A3 5-A2 0 - 5 V DC EHUMSENS detection voltage, input
5-A4 5-A2 5 V DC 5 V DC supply for HUMPCB, output
5-A6 5-A10 0/5 V DC (pulse) PCM drive clock pulse, output
5-A7 5-A10 0/5 V DC PCM LOCK signal, output
5-A8 5-A10 0/5 V DC PCM on/off, input
5-A9 5-A10 5 V DC 5 V DC control voltage for PCM, output
