2A3/4
3-6-43
Terminals (CN) Voltage Remarks
9-7 9-3 0/5 V DC DUPRSW on/off, input
9-8 9-4 0/5 V DC DUPPCSW on/off, input
9-11 9-9 0/5 V DC DUPESW on/off, input
9-12 9-10 5/0 V DC SRHPSW on/off, input
9-13 9-9 5 V DC 5 V DC supply for DUPESW, output
9-14 9-10 5 V DC 5 V DC supply for SRHPSW, output
9-15 9-17 5 V DC 5 V DC supply for STKSW, output
9-16 9-17 0/5 V DC STKSW on/off, input
9-19 9-22 0/5 V DC PWSW-U (DIG0) on/off, input (inch specs)
9-20 9-22 0/5 V DC PWSW-U (DIG1) on/off, input (inch specs)
9-21 9-22 0/5 V DC PWSW-U (DIG2) on/off, input (inch specs)
9-23 9-26 0/5 V DC PWSW-L (DIG0) on/off, input (inch specs)
9-24 9-26 0/5 V DC PWSW-L (DIG1) on/off, input (inch specs)
9-25 9-26 0/5 V DC PWSW-L (DIG2) on/off, input (inch specs)
10-1 12-B6 0/5 V DC (pulse) SRM coil energization pulse, output (B_)
10-2 12-B6 0/5 V DC (pulse) SRM coil energization pulse, output (A_)
10-3 12-B6 0/5 V DC (pulse) SRM coil energization pulse, output (B)
10-4 12-B6 0/5 V DC (pulse) SRM coil energization pulse, output (A)
10-5, -6 12-B7 24 V DC 24 V DC supply for SRM, output
10-7 12-B7 24 V DC 24 V DC supply for DUPFWDSOL, output
10-8 12-B7 0/24 V DC DUPFWDSOL on/off, output
10-9 12-B7 24 V DC 24 V DC supply for SBFSSOL, output
10-10 12-B7 0/24 V DC SBFSSOL latch-on signal, output
10-12 12-B7 0/24 V DC SBFSSOL release signal, output
10-13 12-B7 24 V DC 24 V DC supply for DUPPTSOL, output
10-14 12-B7 0/24 V DC DUPPTSOL on/off, output
11-1 11-5 0/5 V DC (pulse) PFM drive clock pulse, output
11-2 11-5 0/5 V DC PFM LOCK signal, input
11-3 11-5 0/5 V DC PFM on/off, output
11-4 11-5 5 V DC 5 V DC supply for PFM, output
11-8, -9 11-6, -7 24 V DC 24 V DC supply for PFM, output
12-A1 12-B7 24 V DC 24 V DC supply for FCL5, output
12-A2 12-B7 0/24 V DC FCL5 on/off, output
12-A3 12-B7 24 V DC 24 V DC supply for FCL1, output
12-A4 12-B7 0/24 V DC FCL1 on/off, output
12-A7 12-B7 24 V DC 24 V DC supply for FCL2, output
12-A8 12-B7 0/24 V DC FCL2 on/off, output
