Kyocera KM-4230

2A3/4
3-6-46
Terminals (CN) Voltage Remarks
19-A10 19-B9 24 V DC 24 V DC supply for key card*
3
, output
19-B1 19-B9 0/5 V DC Key card*
3
control signal, output
19-B2 19-B9 0/5 V DC Key card*
3
control signal, output
19-B3 19-B9 0/5 V DC Key card*
3
control signal, output
19-B4 19-B9 0/5 V DC Key card*
3
control signal, output
19-B5 19-B9 0/5 V DC Key card*
3
control signal, output
19-B6 19-B9 0/5 V DC Key card*
3
control signal, output
19-B7 19-B9 0/5 V DC Key card*
3
control signal, output
19-B8 19-B9 0/5 V DC Key card*
3
control signal, output
19-B10 19-B10 0/5 V DC Key card*
3
on/off, output
20-1 20-4 24 V DC 24 V DC supply for key card*
3
, output
20-2 20-4 0/5 V DC Key card*
3
, key counter*
1
copy count
signal, output
20-3 20-4 0/5 V DC Key card*
3
, key counter*
1
connected/not
connected, input
21-2 21-1 0/5 V DC (pulse) Finisher*
1
serial signal, output
21-4 21-3 0/5 V DC (pulse) Finisher*
1
serial signal, input
21-5 21-1 0/5 V DC Finisher*
1
RESET signal, output
21-6 21-1 0/5 V DC Finisher*
1
connected/not connected, input
*1: Optional. *3: Optional for 120 V specifications only.
