2A3/4
3-6-52
Terminals (CN) Voltage Remarks
2-A14 2-A13 0/5 V DC MCPCB1 control signal MCP IDA, input
2-A16 2-A15 0/5 V DC MCPCB1 control signal MCP IDB, input
2-B1 2-B6 0/5 V DC MCPCB1 control signal SEMCP MCP1,
input
2-B2 2-B6 0/5 V DC MCPCB1 RESET signal, output
2-B3 2-B6 0/5 V DC MCPCB1 image control signal WCK, output
2-B4 2-B6 0/5 V DC (pulse) MCPCB1 control signal OVSYNC, output
2-B5 2-B6 0/5 V DC MCPCB1 image control signal MRE, output
2-B8 2-B7 0/5 V DC (pulse) MCPCB1 image control signal DATA0,
output
2-B9 2-B7 0/5 V DC (pulse) MCPCB1 image control signal DATA1,
output
2-B10 2-B7 0/5 V DC (pulse) MCPCB1 image control signal DATA2,
output
2-B11 2-B7 0/5 V DC (pulse) MCPCB1 image control signal DATA3,
output
2-B12 2-B7 0/5 V DC (pulse) MCPCB1 image control signal DATA4,
output
2-B13 2-B7 0/5 V DC (pulse) MCPCB1 image control signal DATA5,
output
2-B14 2-B7 0/5 V DC (pulse) MCPCB1 image control signal DATA6,
output
2-B15 2-B7 0/5 V DC (pulse) MCPCB1 image control signal DATA7,
output
3-A1 3-A4 0/5 V DC MCPCB2*
2
image control signal MCPSEL,
output
3-A2 3-A4 0/5 V DC (pulse) MCPCB2*
2
serial communication signal,
output
3-A3 3-A4 0/5 V DC (pulse) MCPCB2*
2
communication control signal
MCP2 ACK, input
3-A5 3-A4 0/5 V DC (pulse) MCPCB2*
2
serial communication signal,
input
3-A6 3-A4 0/5 V DC MCPCB2*
2
control signal ENGACK MCP2,
output
3-A7 3-A4 0/5 V DC (pulse) MCPCB2*
2
communication control signal R
RDY MCP2, input
3-A8 3-A4 0/5 V DC (pulse) MCPCB2*
2
communication control signal W
RDY MCP2, input
3-A9 3-A4 0/5 V DC (pulse) MCPCB2*
2
control signal PVSYNC, output
3-A10 3-A4 0/5 V DC (pulse) MCPCB2*
2
image control signal PHSYNC,
output
*2: 42 ppm: optional/52 ppm: standard.
