Kyocera KM-4230

2A3/4
3-6-63
Terminals (CN) Voltage Remarks
1-1 1-10, -11 0/5 V DC CCD drive clock signal φ CLK +, input
1-2 1-10, -11 0/5 V DC CCD drive clock signal φ CLK –, input
1-3 1-10, -11 0/5 V DC CCD drive clock signal φ RS +, input
1-4 1-10, -11 0/5 V DC CCD drive clock signal φ RS –, input
1-5 1-10, -11 0/5 V DC CCD drive clock signal φ CLP +, input
1-6 1-10, -11 0/5 V DC CCD drive clock signal φ CLP –, input
1-7 1-10, -11 0/5 V DC CCD drive clock signal φ SHIFT +, input
1-8 1-10, -11 0/5 V DC CCD drive clock signal φ SHIFT –, input
1-9 1-10, -11 5 V DC 5 V DC supply for CCDPCB, input
2-1 2-6, -7 CCD control signal VO_O +, output
2-2 2-6, -7 CCD control signal VO_O –, output
2-3 2-6, -7 CCD control signal VO_E +, output
2-4 2-6, -7 CCD control signal VO_E –, output
2-5 2-6, -7 12 V DC +12 V DC supply for CCDPCB, input
