2A3/4
1-3-71
• When the right cassette is empty, its lift serves as a guide for the paper being
conveyed from the left cassette lift.
PFCL1
CN5-6
CN4-4 CN9-5
PDMPCBI/FPCB
PFCL1 PFCL1
CN1-4
PFSW4 (copier)
PFSW4 (copier)
Figure 1-3-58 Right cassette primary paper feed section block diagram
