2FB/2FC-4
1-5-14
(12)
A paper jam in the
paper feed section is
indicated during
copying (multiple
sheets in paper feed
section 1).
Jam code 24
Broken feed switch 5 actua-
tor.
Check visually and replace feed switch 5 if its actuator is broken.
Defective feed switch 5. Run maintenance item U031 and turn feed switch 5 on and off
manually. Replace feed switch 5 if indication of the corresponding
sensor on the touch panel is not displayed in reverse.
Defective timing switch 3. Run maintenance item U031 and turn timing switch 3 on and off
manually. Replace feed switch 5 if indication of the corresponding
sensor on the touch panel is not displayed in reverse.
The vertical feed roller is
dirty with paper powder.
Check and, if it is dirty, clean it.
The vertical feed roller is
deformed or worn.
Check and, if it is deformed or worn, fix or replace it.
(13)
A paper jam in the
paper feed section is
indicated during
copying (multiple
sheets in paper feed
section 2).
Jam code 25
Broken feed switch 4 actua-
tor.
Check visually and replace feed switch 4 if its actuator is broken.
Defective feed switch 4. Run maintenance item U031 and turn feed switch 4 on and off
manually. Replace feed switch 4 if indication of the corresponding
sensor on the touch panel is not displayed in reverse.
Broken feed switch 5 actua-
tor.
Check visually and replace feed switch 5 if its actuator is broken.
Defective feed switch 5. Run maintenance item U031 and turn feed switch 5 on and off
manually. Replace feed switch 5 if indication of the corresponding
sensor on the touch panel is not displayed in reverse.
Defective timing switch 2. Run maintenance item U031 and turn the timing switch 2 on and
off manually. Replace the timing switch 2 if indication of the corre-
sponding sensor on the touch panel is not displayed in reverse.
The vertical feed roller is
dirty with paper powder.
Check and, if it is dirty, clean it.
The vertical feed roller is
deformed or worn.
Check and, if it is deformed or worn, fix or replace it.
(14)
A paper jam in the
paper feed section is
indicated during
copying (multiple
sheets in paper feed
section).
Jam code 26
Broken feed switch 3 actua-
tor.
Check visually and replace feed switch 3 if its actuator is broken.
Defective feed switch 3. Run maintenance item U031 and turn feed switch 3 on and off
manually. Replace feed switch 3 if indication of the corresponding
sensor on the touch panel is not displayed in reverse.
Broken feed switch 4 actua-
tor.
Check visually and replace feed switch 4 if its actuator is broken.
Defective feed switch 4. Run maintenance item U031 and turn feed switch 4 on and off
manually. Replace feed switch 4 if indication of the corresponding
sensor on the touch panel is not displayed in reverse.
The vertical feed roller is
dirty with paper powder.
Check and, if it is dirty, clean it.
The vertical feed roller is
deformed or worn.
Check and, if it is deformed or worn, fix or replace it.
Problem
Causes/check procedures
Corrective measures
