2FB/2FC
1-1-4
Figure 1-1-2
2223
26
29
28
24 23
27
25
3031
32
33
34
35
36
37
38
39
41
40
22. Original table
23. Original width guides
24. Cleaning cloth compartment
25. Original loaded Indicator
26. Document processor top cover
27. Ejection guide
28. Document processor angle adjustment lever
29. Original eject table
30. Toner container
31. Toner container release lever
32. Paper conveyor
33. Knob A1
34. Lever A2
35. Knob A3
36. Duplex unit
37. Deck conveying unit
38. Paper width guides
39. Paper width adjusting tab
40. Paper length guide
41. Paper length adjusting tab
