2FB/2FC
1-6-18
5. Remove the connector and then remove the
MP tray.
Figure 1-6-37
6. Remove the connector and two screws and
then remove the MP unit.
Figure 1-6-38
MP tray
Connector
MP unit
Connecto
r
