Kyocera KM-8030 - Page 39

2FB/2FC
1-3-4
5. Remove the machine cover and pull out the
handles on machine left and right.
6. Lift the machine each left and right one side,
and then remove the lower left and right
spacers.
7. Move the machine alongside slopes to slide
to the floor.
Figure 1-3-3
Slope
Slope
