2FB/2FC
1-3-7
6. Pull out cassette 1 and 2, then remove two
deck spacers.
7. Remove the tape from the deck spacer of
cassette 1 and then remove the guide case.
Figure 1-3-9
8. Pull out cassette 3 and 4, then remove two
cassette spacers and tapes.
Figure 1-3-10
1. Open the front cover and remove two
screws.
Figure 1-3-11
Deck spacer
Guide case
Tap e
Deck spacer
Cassette spacer
Tap e
Remove the screws.
Screws
To Next Page
