Kyocera KM-8030

2FB/2FC
2-3-43
YC5
1 REG MOT/B O 0/24 V DC
(pulse)
Registration motor drive signal
Connected
to the regis-
tration
motor, feed
motor,
duplex side
registration
motor and
duplex
switchback
motor
2DUP FEED
MOT/B
O 0/24 V DC
(pulse)
Duplex feed motor drive signal
3 24V O 24 V DC 24 V DC power output
4DUP FEED
MOT B
O 0/24 V DC
(pulse)
Duplex feed motor drive signal
5 REG MOT B O 0/24 V DC
(pulse)
Registration motor drive signal
6DUP FEED
MOT A
O 0/24 V DC
(pulse)
Duplex feed motor drive signal
7 REG MOT A O 0/24 V DC
(pulse)
Registration motor drive signal
8DUP FEED
MOT/A
O 0/24 V DC
(pulse)
Duplex feed motor drive signal
9 24V O 24 V DC 24 V DC power output
10 DUP SIDE MOT
A
O 0/24 V DC
(pulse)
Duplex side registration motor drive signal
11 REG MOT/A O 0/24 V DC
(pulse)
Registration motor drive signal
12 DUP SIDE MOT
B
O 0/24 V DC
(pulse)
Duplex side registration motor drive signal
13 FEED MOT/B O 0/24 V DC
(pulse)
Feed motor drive signal
14 DUP SIDE
MOT/A
O 0/24 V DC
(pulse)
Duplex side registration motor drive signal
15 24V O 24 V DC 24 V DC power output
16 DUP SIDE
MOT/B
O 0/24 V DC
(pulse)
Duplex side registration motor drive signal
17 FEED MOT B O 0/24 V DC
(pulse)
Feed motor drive signal
18 DUP SB MOT A O 0/24 V DC
(pulse)
Duplex switchback motor drive signal
19 FEED MOT A O 0/24 V DC
(pulse)
Feed motor drive signal
20 DUP SB MOT B O 0/24 V DC
(pulse)
Duplex switchback motor drive signal
21 24V O 24 V DC 24 V DC power output
22 DUP SB MOT/A O 0/24 V DC
(pulse)
Duplex switchback motor drive signal
23 FEED MOT/A O 0/24 V DC
(pulse)
Feed motor drive signal
24 DUP SB MOT/B O 0/24 V DC
(pulse)
Duplex switchback motor drive signal
YC6 1 5V O 5 V DC 5 V DC power output
Connected
to the con-
veying unit
2 REG SW I 0/5 V DC Registration switch: On/off
3 SGND - - Signal ground
4 5V O 5 V DC 5 V DC power output
5 FEED A SW I 0/5 V DC Feed switch 1: On/off
6 SGND - - Signal ground
7 5V O 5 V DC 5 V DC power output
8 EJECT SW I 0/5 V DC Exit switch: On/off
9 SGND - - Signal ground
10 5V O 5 V DC 5 V DC power output
11 FS SW I 0/5 V DC Feedshift switch: On/off
12 SGND - - Signal ground
Connector Pin No. Signal I/O Voltage Description
