2FB/2FC
2-3-51
YC3 1 FMCOMA O 24 V DC 24 V DC power output
Connected
to the origi-
nal feed
motor and
DP lift motor
2 FMCOMB O 24 V DC 24 V DC power output
3 FMA O 0/24 V DC
(pulse)
Original feed motor drive signal
4 FMB O 0/24 V DC
(pulse)
Original feed motor drive signal
5 FM_A O 0/24 V DC
(pulse)
Original feed motor drive signal
6 FM_B O 0/24 V DC
(pulse)
Original feed motor drive signal
7 LM_B O 0/24 V DC
(pulse)
DP lift motor drive signal
8 LMB O 0/24 V DC
(pulse)
DP lift motor drive signal
9 LMA O 0/24 V DC
(pulse)
DP lift motor drive signal
10 LM_A O 0/24 V DC
(pulse)
DP lift motor drive signal
YC4 1 RMCOMA O 24 V DC 24 V DC power output
Connected
to the origi-
nal registra-
tion motor
and original
conveying
motor
2 RMCOMB O 24 V DC 24 V DC power output
3 RMA O 0/24 V DC
(pulse)
Original registration motor drive signal
4 RM_A O 0/24 V DC
(pulse)
Original registration motor drive signal
5 RMB O 0/24 V DC
(pulse)
Original registration motor drive signal
6 RM_B O 0/24 V DC
(pulse)
Original registration motor drive signal
7 CCOMA O 24 V DC 24 V DC power output
8 CCOMB O 24 V DC 24 V DC power output
9 CMA O 0/24 V DC
(pulse)
Original conveying motor drive signal
10 CMB O 0/24 V DC
(pulse)
Original conveying motor drive signal
11 CM_A O 0/24 V DC
(pulse)
Original conveying motor drive signal
12 CM_B O 0/24 V DC
(pulse)
Original conveying motor drive signal
YC5 1 GREEN O 0/5 V DC LED green: On/off
Connected
to the LED
PWB
2 GND - - Signal ground
3 RED O 0/5 V DC LED red: On/off
YC6 1 5V O 5 V DC 5 V DC power output
Connected
to the origi-
nal set
switch, DP
lift upper
limit switch
and DP lift
lower limit
switch
2 SET SW I 0/5 V DC Original set switch: On/off
3 SGND - - Signal ground
4 SGND - - Signal ground
5 5V O 5 V DC 5 V DC power output
6 LHSW I 0/5 V DC DP lift upper limit switch: On/off
7 SGND - - Signal ground
8 5V O 5 V DC 5 V DC power output
9 LLSW I 0/5 V DC DP lift lower limit switch: On/off
10 SGND - - Signal ground
Connector Pin No. Signal I/O Voltage Description
