L-Acoustics A15 Series User Manual

System components
KS21-PLA Removable front dolly for 1KS21
KS21-COV Protective cover for 1 KS21
KS21-CHARIOTCOV Protective cover for 3 KS21 on KS21-CHARIOT
Software applications
Soundvision 3D acoustical and mechanical modeling software
LA Network Manager Software for remote control and monitoring of amplied controllers
Refer to the Soundvision help.
Refer to the LA Network Manager help.
Loudspeaker cables
0.7 m / 5 m / 10 m / 25 m
CH(1)
CH(2)
1 m
SP.7 / SP5 / SP10 / SP25 SP-Y1
0.7 m / 10 m / 25 m
SPK1
SPK2
SPK3
SPK4
5 m
DO.7 / DO10 / DO25 DOSUB-LA8
10 A15 owner's manual (EN) version 1.2

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
