L-Acoustics A15 Series User Manual

Electro-acoustical description
Connectors
SpeakON connectors can be used interchangeably as IN or LINK connector.
A15 Focus
2 × 4-point speakON
A15 Wide
2 × 4-point speakON
Internal pinout for L-Acoustics 2-way passive enclosures
speakON points 1 + 1 - 2 + 2 -
Transducer connectors + - Not linked Not linked
KS21
2 × 4-point speakON
Internal pinout for L-Acoustics subwoofers
speakON points 1 + 1 - 2 + 2 -
Transducer connectors LF + LF - Not linked Not linked
A15 owner's manual (EN) version 1.2 19

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
