L-Acoustics A15 Series User Manual

Mechanical safety
Mechanical safety
Flown congurations
The A15 rigging system complies with 2006/42/EC: Machinery Directive. It has been designed following the guidelines
of BGV-C1.
2006/42/EC: Machinery Directive species a safety factor of 4 against the rupture. The own deployments described in
this manual achieve a safety factor of 4 or more.
Refer to Soundvision for the safety factor of a specic deployment.
The safe limit gives the maximum number of elements for which the safety factor is compliant with the 2006/42/
EC: Machinery Directive, within the use dened in this manual and regardless of the other deployment parameters (site
angles, inter-enclosure angles, etc.).
The maximum limit gives the maximum number of elements for which the safety factor can be compliant with the
2006/42/EC: Machinery Directive, when the other deployment parameters provide the best mechanical conditions.
For mixed arrays refer to your Soundvision model.
KS21
conguration rigging accessory safe limit maximum limit
Vertical array A15-BUMP 8 16
Vertical array A15-RIGBAR 4
A15 Wide/Focus
conguration rigging accessory maximum / safe limit
Flown X-BAR 1
Vertical array A15-BUMP + M-BAR (optional) 8
Vertical array A15-RIGBAR 4
1 × A15-LIFT 1 or 3
2 × A15-LIFT 2, 4, 5 or 6
Radial array
3 × A15-LIFT 7, 8 or 9
Other congurations
For other congurations, respect the recommended maximum limit for optimal stability.
Use safety straps
Always use safety straps on stacked arrays where the enclosures are not connected by the rigging system.
Always use safety straps on stacked arrays higher than four enclosures.
KS21
conguration rigging accessory maximum / safe limit
Stacked vertical array No rigging accessory or KS21-OUTRIG (optional) 4
Stacked upright No rigging accessory 3
Stacked on chariot KS21-CHARIOT 3
A15 owner's manual (EN) version 1.2 43

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
