L-Acoustics A15 Series User Manual

Rigging system description
Enclosures
A15 Wide/Focus
A15 Wide/Focus feature two lodgings to create radial arrays with A15-LIFT (p.29).
A DIN580-compatible M8 threaded insert is available to implement a secondary safety.
Two sets of two lodgings and one insert provide further options for ying, stacking or pole-mounting a single enclosure or
small arrays with X-BAR (p.38), A-TILT (p.32), or A-MOUNT (p.37), respectively.
22 A15 owner's manual (EN) version 1.2

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
