L-Acoustics A15 Series User Manual

Loudspeaker congurations
Loudspeaker congurations
A15 Wide/Focus line source
In this conguration the system operates over the nominal bandwidth of the enclosures.
The [A15] preset delivers a reference frequency response in medium throw applications.
The A15 Wide/Focus enclosures are driven by the LA4X / LA8 / LA12X amplied controllers.
Preset [A15]
Frequency range (-10 dB)
41 Hz - 20 kHz (A15 Focus)
42 Hz - 20 kHz (A15 Wide)
A15 owner's manual (EN) version 1.2 45

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
