L-Acoustics A15 Series User Manual

Rigging procedures
Flying a single enclosure with X-BAR
Type of deployment own
X-BARRigging accessories
1 x Ø12 mm shackle WLL 1 t (provided) or CLAMP250
Min number of operators 1
Additional safety for own arrays
When ying an enclosure or an array, use the M8 DIN580 threaded insert to implement a secondary safety.
Realized site angles
A15 Focus A15 WideX-BAR hole N
o
rear extension front extension rear extension front extension
1 8.4 -10 6.9 -13.6
2 -0.5 -1 -2.8 -3.4
3 -9.4 7.8 -13.2 6.5
4 -18.5 16.2 -23.7 15.7
5 -27.5 24.8 -34.6 25.1
Assembly
Procedure
1. Drive the X-BAR in the insert.
64 A15 owner's manual (EN) version 1.2

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
