L-Acoustics A15 Series User Manual

Rigging system description
The pickup points are compatible with Ø12 mm shackles WLL 1 t (two provided) and CLAMP250.
When using A15-RIGBAR as the main lifting accessory, always implement a secondary safety using available
holes.
One pickup point
safety points
pickup point
Two pickup points
pickup points
safety point
A15-LIFT
A15-LIFT is a rigging element designed to y a radial array of up to three A15 Wide/Focus.
A15-LIFT features two studs that match the lodgings at the front and rear of the enclosure.
studs
A15 owner's manual (EN) version 1.2 29

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
