L-Acoustics A15 Series User Manual

Recommendation for speaker cables
Recommendation for speaker cables
Follow the recommended maximum length for loudspeaker cables to ensure minimal SPL attenuation.
Cable quality and resistance
Only use high-quality fully insulated speaker cables made of stranded copper wire.
Use cables with a gauge offering low resistance per unit length and keep the cables as short as possible.
The table below provides the recommended maximum length for loudspeaker cables depending on the cable gauge and
on the impedance load connected to the amplier.
recommended maximum lengthcable gauge
8 Ω load 4 Ω load 2.7 Ω load
mm
2
SWG AWG m ft m ft m ft
2.5 15 13 30 100 15 50 10 33
4 13 11 50 160 25 80 17 53
6 11 9 74 240 37 120 25 80
For installation projects, use the more detailed L-Acoustics calculation tool to evaluate cable length and gauge based on
the type and number of enclosures connected. The calculation tool is available on our website:
https://www.l-acoustics.com/en/installation/tools/
A15 owner's manual (EN) version 1.2 97

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
