L-Acoustics A15 Series User Manual

Authorized congurations with A15-LIFT
Authorized congurations with A15-LIFT
Safety instructions
Additional safety with A15-LIFT
On each enclosure on which A15-LIFT is secured, secure a DIN580 eye bolt to the dedicated insert to implement
a secondary safety.
Use a shackle and a steel wire rope. Make sure the steel rope is as tensed as possible without bearing the load.
A15-LIFT quantity and position
Use one A15-LIFT for up to three enclosures in the array.
Do not leave more than two adjacent enclosures unsupported.
A15-LIFT pickup point
Select the same pickup point on each A15-LIFT within an array of up to 6 enclosures.
For larger arrays, refer to Radial arrays of 7 enclosures and more (p.95).
Risk of tilting
When using a single motor or a bridle, make sure the array is symmetrical.
When using a third-party bridle, make sure the angle between the two chains does not exceed 60°.
Hybrid congurations
Either A15 Wide, A15 Focus or a combination of both can be used as illustrated.
94 A15 owner's manual (EN) version 1.2

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
