L-Acoustics A15 Series User Manual

Rigging system description
Two runners on each KS21-OUTRIG bar ensure stability. Four
∅
6.5 mm holes are available to secure the assembly to the
oor.
⌀6.5 mm hole (x4)
K2-JACK
K2-JACK is a set of a two bars and four feet with screw jacks and hand wheels. K2-JACK can be tted onto KS21-
CHARIOT (p.40) to improve stability or correct oor discrepancies.
During transportation, make sure the bolts are tightened.
bolts (x4)
feet with screw jacks
locking handles
hand wheels
storage position position in use
A15 owner's manual (EN) version 1.2 35

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
