L-Acoustics A15 Series User Manual

Rigging system description
Rigging elements for a single enclosure
A-MOUNT
A-MOUNT is a 35 mm (1-
⅜
") pole-mount adapter for a single A15 Wide/Focus.
A-MOUNT is secured to the enclosure with a threaded knob and tightened onto the pole with a wedge clamp. Two studs
are used for indexation with the lodgings on the enclosure. A-MOUNT features two axis: the front one can be moved to
change the site angle.
studs
angle axis
enclosure knob
(in use)
wedge clamp
position in use
The enclosure knob can be stored in an insert on the side.
The angle axis is secured with a threaded knob. To optimize visual impact, the knob can be replaced by a locking cotter
pin (provided).
enclosure knob
(stored)
enclosure knob
(stored)
storage position storage position with locking cotter pin
A15 owner's manual (EN) version 1.2 37

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
