L-Acoustics A15 Series User Manual

Rigging system description
Storage and handling elements
KS21-CHARIOT
KS21-CHARIOT is a chariot designed to transport a stack of up to three KS21. It features two rigging arms to secure the
lower KS21.
Risk of damage
Do not secure A15 Wide/Focus directly on KS21-CHARIOT.
Do not move or transport more than three enclosures on KS21-CHARIOT.
1904 mm / 75 in
KS21-CHARIOT features two brakes for optimal stability.
Risk of brake damage
Do not use the brakes during transportation.
40 A15 owner's manual (EN) version 1.2

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
